Penrith Panthers Western Sydney Conference, Community Centres and Hotel

Penrith, NSW

The WSCCC development comprises 2 levels of basement parking, a conference centre with 1250m2 of flexible space, a 1200m2 community centre and a 4.5 star hotel accomodating 153 beds.

TTW worked closely with the architect to optimise the basement levels, reconfiguring parking layouts to minimise transfer structures and rationalise the structural arrangement, and where required consolidated transfers into a single transfer level at ground floor, whilst the lowest basement levels were selected to sit above expected water table fluctuations to design out requirements for tanked walls and basement slabs. Below basement, tanks are designed for uplift buoyancy with the deep pump out tanks held down with tension piles.

The structure comprises of solder piled shoring with temporary ground anchors, post-tensioned banded slabs to the basement, ground and level 1 structure, with post-tensioned flat plate construction utilised for the hotel floor levels. At level 2 a large steel structure provides the roof to the conference and community centres, the prefunction lobby spaces and coverage to the entry and external terraced areas. The roof incorporates cantilevers exceeded 6m, whilst 31m spanning steel trusses are utilised to provide the column-free flexible space to the conference centre.

The basements provide over 14,000m2 of space which house car parking, plant rooms, storage and staff facilities.



Client: Penrith Rugby Club Limited

Architect: Turner Studio

Builder: Richard Crookes Construction

Value: $88M

Completion: 2022

Sector: Sports & Leisure

Services: Structural
